Up to 2 Sockets
Up to 4 Drives
Up to 6 PCIe Slots
Touchable LCD Module
Intelligent Management System
Intelligent Cooling System
Intelligent Monitoring System
88 RAS Features
|
Detailed Specification |
|
|
CPU |
2 4th/5th Generation Intel®Xeon SP series 225W power consumption |
|
Chipset |
Intel® C741 |
|
Memory |
16 DDR5 RDIMM Slots, 5600 MT/s Data Rate |
|
Raid Controller |
Embedded RAID controller (SATA RAID 0,1,5) Mezzanine RAID HBA controller (SATA/SAS RAID 0,1) Mezzanine RAID storage controllers (SATA/SAS 0,1,10,5,6,50,60) |
|
FBWC |
4 GB Cache, support Supercapacitor protection* |
|
Storage |
Front 3SFF bays* Front SAS/SATA HDD/SSD/NVMe Drives, maximum 2 NVMe Drives Front/Embedded 2 M.2 SSDs |
|
Network |
2 Onboard 1 Gbps Ports Internal Mezzanine Slots for 4x10GE, 2x10GE, 2x25GE, 2x16GE, 2 x32GE NIC Front PCIe Standard Slots for Ethernet adapter |
|
Expansion Slots |
6 PCIe Slots 2 Standard PCIe 5.0 Slots, 3 Mezzanine Slots, 1 RAID-dedicated Slot |
|
Ports |
1 Front USB 3.0 Port, 1 SUV Port (2 USB2.0, Serial Port, VGA Port) |
|
GPU |
2 LP GPU Modules |
|
Optical Drive |
External Optical Disk Drive, Optional |
|
Management |
Chassis integrated |
|
Security |
TPM2.0 |
|
Power supply |
Chassis integrated |
|
Operating temperature |
5°C to 45°C (41°F to 113°F) * |
|
Dimensions |
Single Height and Half Width |
*The Options may be different depending on the specific requirement, refer to related User Guide
